图片展示

Smart POS

All In One Smart Payment POS HZ-CS10, Android Handheld Mobile Pos Machine, Pos Terminal With Printer For E-wallet, Topup , Bus Ticket , Parking, Android Handheld POS Machine, POS Terminal with Printer for E-wallet Application, top up, Bus Ticket Printer,

stock quantity :

Select the number of specifications

Please check the product information you want!

Product Detail


CS10 is the cutting-edge secure electronic payment terminal,empowered by Quad-core CPU and massive memory, CS10 enables exceptionally fast processing of applications, and supports additional features for local customization including fingerprint scanner and fiscal module. It is your smart choice for one-stop payment and service.

Ø Safedroid OS, Based on Android 7.0 OS;
Ø 5.5 inch TFT IPS LCD, resolution 1280*720
Ø Built-in high speed thermal printer , with over 50Km print life
Ø Full bands for global coverage: 4G/3G/2G,WLAN,VPN
Ø Authentec,508dpi fingerprint module for biometric identification
Ø  Dual camera for quickly QR code scan & Honeywell 2D scanner as option
Ø  One-stop payment of MSR/IC/NFC, with PCI PTS 5.X, EMV L1&L2 certified


Demo Show:  https://youtu.be/EnVZUunmeMk



Specifications

Basic

Characteristics

OS

Safe Adroid OS (based on Android 7.0)

CPU

Quad-Core 1.35GHZ

ROM

8GB ROM   EMMC

RAM

1G RAM   LPDDR3

Display

5.5 inch   TFT IPS LCD,resolution 1280*720

Panel

Ultra sensitive capacitivetouch screen, can work with gloves and wet fingers

Dimensions

206mmX84mmX32mm (max 56mm)

Weight

530g(Battery   included)

Keys

3 Physical   keys:1 ON/OFF KEY,2 Shortcut keys

3 Virtual keys:Menu,Home,Back

Input

Chinese/English   ,and supports handwriting and soft keyboard

Radio Communication

WIFI

IEEE   802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ

Bluetooth

BT 4.0 LE   +EDR

4G

TD-LTE:Band38,   Band39, Band40, Band41

FDD-LTE:Band1,Band3,Band7,Band8,Band20

3G

UMTS(WCDMA)/HSPA+:Band1,Band8,Band2,Band5

CDMA EV-DO   Rev.A:800MHZ

TD-SCDMA:Band34,Band39

2G

GSM/GPRS/EDGE:850/900/1800/1900MHZ

Payment

Magcard   reader

Supports ISO7811/7812/7813, and   supports triple

track (tracks 1/2/3),   bi-directional

Smart Card reader

Supports ISO7816 standard

Contactless Card reader

Supports 14443A / 14443B

Expansion and peripherals

Printer

High-Speed Thermal Printer ;

58mm printing paper ;

40mm paper roll

Camera

5MP camera with LED flash and   auto-focus function

Satellite   Positioning

GPS, Supports A-GPS

Audio

Speaker ,Microphone,Earphone

Interfaces

Micro SD Card Slot

1 PCS

SIM Card   Slot

2 PCS MICRO SIM

PSAM Card   Slot

2 PCS Conforms to ISO7816   standard

USB Port

1PCS TYPE C USB

Power

Battery

Li-ion battery ,7.4V /2600mAH

Charging Port

Type C USB Port ,5V DC,2A

Environment

Operating   Temperature

-10°C to   50°C

Storage   Temperature

-20°C to 70°C

Humidity

5% to 95% Relative Humidity,   Non-Condensing

Certification

Electromagnetic

CERoHS,FCC

Payment

PCI PTS 5.X ,EMV L1&L2,Paypass , Paywave

   Optional

Fingerprint

Semiconductor capacitance

18mm x 12.8mm imaging area 256 x 360 pixel array,

Crossmatch FBI certified  508dpi

Front camera

2 Megapixel Fixed Focal Camera

Barcode Scanner

Honeywell 2D Image Engine, Support   1D and 2D symbologies

Satellite Position

GLONASS,   Bei-Dou satellite navigation system

Fiscal Module

Russian format


No comment

Product Detail


CS10 is the cutting-edge secure electronic payment terminal,empowered by Quad-core CPU and massive memory, CS10 enables exceptionally fast processing of applications, and supports additional features for local customization including fingerprint scanner and fiscal module. It is your smart choice for one-stop payment and service.

Ø Safedroid OS, Based on Android 7.0 OS;
Ø 5.5 inch TFT IPS LCD, resolution 1280*720
Ø Built-in high speed thermal printer , with over 50Km print life
Ø Full bands for global coverage: 4G/3G/2G,WLAN,VPN
Ø Authentec,508dpi fingerprint module for biometric identification
Ø  Dual camera for quickly QR code scan & Honeywell 2D scanner as option
Ø  One-stop payment of MSR/IC/NFC, with PCI PTS 5.X, EMV L1&L2 certified


Demo Show:  https://youtu.be/EnVZUunmeMk



Specifications

Basic

Characteristics

OS

Safe Adroid OS (based on Android 7.0)

CPU

Quad-Core 1.35GHZ

ROM

8GB ROM   EMMC

RAM

1G RAM   LPDDR3

Display

5.5 inch   TFT IPS LCD,resolution 1280*720

Panel

Ultra sensitive capacitivetouch screen, can work with gloves and wet fingers

Dimensions

206mmX84mmX32mm (max 56mm)

Weight

530g(Battery   included)

Keys

3 Physical   keys:1 ON/OFF KEY,2 Shortcut keys

3 Virtual keys:Menu,Home,Back

Input

Chinese/English   ,and supports handwriting and soft keyboard

Radio Communication

WIFI

IEEE   802.11 a/b/g/n ,support dual Band 2.4GHZ and 5GHZ

Bluetooth

BT 4.0 LE   +EDR

4G

TD-LTE:Band38,   Band39, Band40, Band41

FDD-LTE:Band1,Band3,Band7,Band8,Band20

3G

UMTS(WCDMA)/HSPA+:Band1,Band8,Band2,Band5

CDMA EV-DO   Rev.A:800MHZ

TD-SCDMA:Band34,Band39

2G

GSM/GPRS/EDGE:850/900/1800/1900MHZ

Payment

Magcard   reader

Supports ISO7811/7812/7813, and   supports triple

track (tracks 1/2/3),   bi-directional

Smart Card reader

Supports ISO7816 standard

Contactless Card reader

Supports 14443A / 14443B

Expansion and peripherals

Printer

High-Speed Thermal Printer ;

58mm printing paper ;

40mm paper roll

Camera

5MP camera with LED flash and   auto-focus function

Satellite   Positioning

GPS, Supports A-GPS

Audio

Speaker ,Microphone,Earphone

Interfaces

Micro SD Card Slot

1 PCS

SIM Card   Slot

2 PCS MICRO SIM

PSAM Card   Slot

2 PCS Conforms to ISO7816   standard

USB Port

1PCS TYPE C USB

Power

Battery

Li-ion battery ,7.4V /2600mAH

Charging Port

Type C USB Port ,5V DC,2A

Environment

Operating   Temperature

-10°C to   50°C

Storage   Temperature

-20°C to 70°C

Humidity

5% to 95% Relative Humidity,   Non-Condensing

Certification

Electromagnetic

CERoHS,FCC

Payment

PCI PTS 5.X ,EMV L1&L2,Paypass , Paywave

   Optional

Fingerprint

Semiconductor capacitance

18mm x 12.8mm imaging area 256 x 360 pixel array,

Crossmatch FBI certified  508dpi

Front camera

2 Megapixel Fixed Focal Camera

Barcode Scanner

Honeywell 2D Image Engine, Support   1D and 2D symbologies

Satellite Position

GLONASS,   Bei-Dou satellite navigation system

Fiscal Module

Russian format
